5SV6016-7KK20
AFDD-MCB-Combination 230V, 6kA, 1+N, C, 20A Compact (1MW)
- Stock status:
- Call for availability
- Manufacturer:
- Siemens
- Product code:
- 5SV6016-7KK20
Main documents
- Product datasheet
- Instruction sheet
- Catalogue
Related products
| Product | |
| Article Number (Market Facing Number) | 5SV6016-7KK16 |
| Product Description | |
| Product family | SENTRON Arc fault detection device |
| Product Lifecycle (PLM) | Active Product |
| Price data | |
| Region Specific PriceGroup / Headquarter Price Group | 13E / 1BA |
| List Price | Show prices |
| Customer Price | Show prices |
| Surcharge for Raw Materials | None |
| Metal Factor | L-A—– |
| Additional Product Information | |||
| EAN | 4001869565071 | ||
| UPC | Not available | ||
| Commodity Code | 85362010 | ||
| LKZ_FDB/ CatalogID | LV10 | ||
| Product Group | 5546 | ||
| Group Code | P310 | ||
| Country of origin | China | ||
| Compliance with the substance restrictions according to RoHS directive | Since: 01.01.2018 | ||
| Product class | A: Standard product which is a stock item could be returned within the returns guidelines/period. | ||
| WEEE (2012/19/EU) Take-Back Obligation | yes | ||
| REACH Art. 33 Duty to inform according to the current list of candidates |
Lead monoxide (lead oxide) CAS-No. 1317-36-8 > 0,1 % (w / w) | ||
| SCIP number | 4a2cb00b-b1e5-44b4-a168-63c1735a85e5 | ||
Product Description
5SV6016-7KK20
The Siemens 5SV6016-7KK20 is a compact Arc Fault Detection Device (AFDD) combined with a Miniature Circuit Breaker (MCB) that provides enhanced electrical protection by detecting dangerous arc faults and interrupting power supply before they can cause fires. In addition to arc fault detection, it integrates standard MCB protection against overloads and short circuits**, making it a reliable and space-saving solution for modern electrical installations.
Key Features and Specification
- Device Type: AFDD + MCB Combination (Compact, 1 module width)
- Rated Voltage (Un): 230 V AC
- Rated Current (In): 20 A
- Breaking Capacity: 6 kA
- Poles: 1P+N (single-phase with neutral)
- Tripping Characteristic: C-curve (suitable for general loads with moderate inrush currents)
- Mounting: DIN rail
Technical Information
- Number: 5SV6016-7KK20
- EAN: 4001869565088
- Commodity Code: 85362010
- Catalog ID: LV10
- Product Group: 5546
- Group Code: P310
- Lifecycle Status: Active Product
Applications
- Protects against arc faults, overloads, and short circuits in electrical systems
- Reduces fire risks in residential, commercial, and public buildings
- Suitable for lighting circuits, socket outlets, and mixed-use installations
- Saves space by combining AFDD and MCB functions in a single compact device
Summary:
The Siemens 5SV6016-7KK20 is a 20 A, 1P+N, C-curve AFDD/MCB combination device with a 6 kA breaking capacity. Belonging to the SENTRON AFDD product family, it ensures maximum electrical safety by combining arc fault detection technology with short-circuit and overload protection in a single compact module. With full RoHS and REACH compliance, it is a future-proof and reliable choice for safe power distribution.
