In summary, the Siemens 3VA1332-6EF32-0AA0 is a 320 A, 3-pole molded case circuit breaker from the SENTRON 3VA1 series, featuring Class H (70 kA) breaking capacity and TM240 thermal-magnetic trip unit. It provides comprehensive line protection with adjustable overload (Ir) and short-circuit (Ii) settings, ensuring reliable performance, long service life, and robust protection in demanding industrial applications.
Product Catalogue
Download Product Catalogue
100% Genuine Products
Supplier of industrial electrical products
1 year warranty
The products have a warranty
3VA1332-6EF32-0AA0
circuit breaker 3VA1 IEC Frame 400 breaking capacity class M Icu=55 kA @ 415 V 3-pole, starter protection TM120M, AM, In=320 A without overload protection short-circuit protection Ii=7…14 x In nut keeper kit
- Stock status:
- Call for availability
- Manufacturer:
- Siemens
- Product code:
- 3VA1332-6EF32-0AA0
Main documents
- Product datasheet
- Instruction sheet
- Catalogue
Related products
| Product | |
| Article Number (Market Facing Number) | 3VA1332-6EF32-0AA0 |
| Product Description | |
| Product family | 3VA Molded Case Circuit Breakers up to 1600 A, IEC |
| Product Lifecycle (PLM) | Active Product |
| Price data | |
| Region Specific PriceGroup / Headquarter Price Group | 12P / 53J |
| List Price | Show prices |
| Customer Price | Show prices |
| Surcharge for Raw Materials | None |
| Metal Factor | LOA—– |
| General technical data | |
| insulation voltage / rated value | 800 V |
| operating voltage / at DC / rated value | 500 V |
| operating voltage / at AC / rated value | 690 V |
| power loss [W] / maximum | 80.1 W |
| power loss [W] / for rated value of the current / at AC / in hot operating state / per pole | 26.7 W |
| mechanical service life (operating cycles) / typical | 20 000 |
| electrical endurance (operating cycles) / at AC-1 / at 380/415 V | 6 000 |
| electrical endurance (operating cycles) / at AC-1 / at 690 V | 4 200 |
| ground-fault monitoring version | Without |
| WEEE (2012/19/EU) Take-Back Obligation | Yes |
| REACH Art. 33 Duty to inform according to the current list of candidates | not available |
| Net Weight | 4.817 kg |
Product Description
Product Overview
Product Name: 3VA1 Molded Case Circuit Breaker
Product Code: 3VA1332-6EF32-0AA0
Brand: Siemens SENTRON
Product Family: 3VA Molded Case Circuit Breakers up to 1600 A (IEC Standard)
Design: Line protection
Trip Unit: TM240 (Thermal-Magnetic)
Protection Type: LI (Overload and short-circuit protection)
Number of Poles: 3P
Life Cycle Status: Active Product
Technical Specifications
Rated Current (In): 320 A
Overload Protection (Ir): Adjustable from 224 A…320 A
Short-Circuit Protection (Ii): Adjustable from 5…10 × In
Breaking Capacity: 70 kA @ 415 V AC (Class H)
Rated Insulation Voltage (Ui): 800 V
Rated Operational Voltage (Ue): 690 V AC
Rated DC Voltage (Ud): 500 V DC
Maximum Power Loss: 80.1 W total
Power Loss per Pole: 26.7 W (at rated current in hot operating state)
Mechanical Durability: 20,000 operations
Electrical Endurance:
6,000 cycles @ 380/415 V AC
4,200 cycles @ 690 V AC
Neutral Conductor Protection: Not available (non-retrofittable)
Ground-Fault Monitoring: Not available
Communication / Measurement Functions: Not available
Net Weight: 4.817 kg
Performance & Features
Line protection type (LI) — provides adjustable overload and short-circuit protection, ensuring optimal safety for feeders and power lines.
Thermal-magnetic trip unit (TM240) — delivers precise and dependable tripping based on both long-time (thermal) and instantaneous (magnetic) current responses.
High breaking capacity (Class H) — with Icu = 70 kA @ 415 V AC, ideal for heavy-duty industrial environments.
Compact 3-pole design enables space-efficient installation and easy integration into switchboards.
Durable construction with up to 20,000 mechanical operations for long-term reliability.
Includes nut keeper kit for secure and simplified mounting.
No communication or measurement modules, providing a simple and maintenance-friendly setup.
Applications
Power distribution and feeder protection
Industrial machinery and automation panels
Motor control centers and switchboards
Systems requiring both overload and short-circuit protection
Suitable for installations where high breaking capacity (70 kA) is required
Summary
Frequently Asked Questions
What is the full form of MCCB in Siemens?
The full form of MCCB is Molded Case Circuit Breaker. A Siemens MCCB is designed to handle high electrical currents, often up to 1000A, making it highly reliable for industrial and commercial applications. These breakers provide advanced protection against overloads and short circuits, ensuring the safety of large electrical systems.
What is the difference between a Molded Case Circuit Breaker (MCB) and an MCCB?
The main difference between an MCB (Miniature Circuit Breaker) and an MCCB (Molded Case Circuit Breaker) lies in their capacity and applications.
✅MCBs are generally used for low-power applications, with a short-circuit breaking capacity of up to 10–15 kA. They are best suited for residential and light commercial systems.
✅ MCCBs, on the other hand, are designed for medium to high-power applications, with a breaking capacity ranging from 15 kA up to 100 kA and current ratings up to 1000A. This makes them ideal for industrial environments where large electrical loads need reliable protection.
Which company circuit breaker is best?
✅ In 2025, the leading circuit breaker brands include Siemens, Schneider Electric, ABB, Eaton, and Legrand. Among them, Siemens MCCBs—especially the Sentron 3VA series—stand out for safety, durability, and advanced circuit protection in industrial and commercial applications.
What breakers work in a Siemens box?
Siemens QT, QP, QAF, and QPF breakers fit Siemens panels. However, not all breakers are interchangeable—e.g., a QT breaker cannot replace a QP breaker. Always check compatibility before replacing.
