5SL6310-7
Miniature circuit breaker 400 V 6kA, 3-pole, C, 10 A
- Stock status:
- In stock
- Manufacturer:
- Siemens
- Product code:
- 5SL6310-7
Main documents
- Product datasheet
- Instruction sheet
- Catalogue
| Product | |
| Article Number (Market Facing Number) | 5SL6310-7 |
| Product Description | Miniature circuit breaker 400 V 6kA, 3-pole, C, 10 A |
| Product family | Basic Devices |
| Product Lifecycle (PLM) | PM300:Active Product |
| Price data | |
| Region Specific PriceGroup / Headquarter Price Group | 11B / 1AC |
| List Price | Show prices |
| Customer Price | Show prices |
| Surcharge for Raw Materials | None |
| Metal Factor | L-O—– |
| Additional Product Information | ||
| EAN | 4001869388748 | |
| UPC | Not available | |
| Commodity Code | 85362010 | |
| LKZ_FDB/ CatalogID | LV10.1 | |
| Product Group | 3803 | |
| Group Code | P310 | |
| Country of origin | Turkiye | |
| Compliance with the substance restrictions according to RoHS directive | Since: 01.10.2006 | |
| Product class | B: return restricted, please contact your Siemens partner/contact | |
| WEEE (2012/19/EU) Take-Back Obligation | Yes | |
| REACH Art. 33 Duty to inform according to the current list of candidates | ||
| SCIP number | 06748f66-a441-48a5-aec9-1a8a4585c58c | |
Product Description
5SL6310-7
The 5SL6310-7 from Siemens is a robust and efficient miniature circuit breaker (MCB) designed to ensure reliable protection against overloads and short circuits in three-phase electrical systems. With a rated voltage of 400 V AC and a breaking capacity of 6 kA, this 3-pole MCB features a Type C tripping characteristic and a rated current of 10 A, making it ideal for protecting circuits with moderate inrush currents, such as lighting systems, socket outlets, and small motors.
Key Features and Specification
Product Code: 5SL6310-7
Rated Voltage: 400 V AC
Breaking Capacity: 6 kA
Number of Poles: 3
Tripping Characteristic: Type C
Rated Current: 10 A
EAN: 4001869388748
Commodity Code: 85362010
Catalog ID: LV10.1
Product Group: 3803
Lifecycle Status: Active Product (PM300)
Applications
- Circuit protection for lighting and socket outlets
- Protection of control circuits and small machines
- General-purpose distribution in residential and commercial systems
- Suitable for installations with moderate inrush currents
Summary:
The Siemens 5SL6310-7 is a reliable 3-pole miniature circuit breaker rated at 10 A. With its Type C tripping curve and 6 kA breaking capacity, it provides consistent and safe protection for a wide range of low-voltage applications.
Frequently Asked Questions
What is the rule for installing an SPD?
✅ SPD (Surge Protection Device) connections should be as short as possible to minimize the voltage protection level (Up). The total length of connections to the network and earth should not exceed 50 cm to ensure effective surge protection.
How to Set Up a Surge Protector?
1.Turn off power at the circuit breaker.
2. Remove the old outlet.
3. Connect wires to the new surge-protected outlet per the manufacturer’s instructions.
4. Secure the outlet in the box and replace the cover plate.
5. Restore power and test the outlet.
What is the use of RCCB in Siemens?
✅ Siemens Residual Current Circuit Breakers (RCCBs) protect against electric shock by detecting leakage currents. If the leakage exceeds a set limit, the RCCB immediately disconnects the circuit, ensuring safety from direct or indirect contact with live components.
Where to Install RCCB?
✅ RCCBs should be installed in the distribution board (DB box) or circuit breaker panel to protect against current leakages caused by faulty wiring, ageing insulation, or defective appliances.
