5SL6225-7
Miniature circuit breaker 400 V 6kA, 2-pole, C, 25A
- Stock status:
- In stock
- Manufacturer:
- Siemens
- Product code:
- 5SL6225-7
Main documents
- Product datasheet
- Instruction sheet
- Catalogue
Related products
| Product | |
| Article Number (Market Facing Number) | 5SL6225-7 |
| Product Description | Miniature circuit breaker 400 V 6kA, 2-pole, C, 25A |
| Product family | Basic Devices |
| Product Lifecycle (PLM) | PM300:Active Product |
| Price data | |
| Region Specific PriceGroup / Headquarter Price Group | 12B / 1AC |
| List Price | Show prices |
| Customer Price | Show prices |
| Surcharge for Raw Materials | None |
| Metal Factor | L-O—– |
| Additional Product Information | ||
| EAN | 4001869388502 | |
| UPC | Not available | |
| Commodity Code | 85362010 | |
| LKZ_FDB/ CatalogID | LV10.1 | |
| Product Group | 3803 | |
| Group Code | P310 | |
| Country of origin | Turkiye | |
| Compliance with the substance restrictions according to RoHS directive | Since: 01.10.2006 | |
| Product class | B: return restricted, please contact your Siemens partner/contact | |
| WEEE (2012/19/EU) Take-Back Obligation | Yes | |
| REACH Art. 33 Duty to inform according to the current list of candidates | ||
| SCIP number | 9619d991-4e7c-4812-8e83-a0b6675c6663 | |
Product Description
5SL6225-7
The 5SL6225-7 from Siemens is a reliable and high-performance miniature circuit breaker (MCB) designed for effective protection against overloads and short circuits in electrical systems. It supports a rated voltage of 400 V AC, a breaking capacity of 6 kA, and comes in a 2-pole configuration with a Type C tripping characteristic. With a rated current of 25 A, this MCB is suitable for protecting higher-load circuits in residential, commercial, and light industrial applications.
Key Features and Specification
- Product Code: 5SL6225-7
- Rated Voltage: 400 V AC
- Breaking Capacity: 6 kA
- Poles: 2
- Tripping Curve: Type C
- Rated Current: 25 A
- Product Family: Basic Devices
- Lifecycle Status: PM300 – Active Product
- EAN: 4001869388502
- Commodity Code: 85362010
- Catalog ID: LV10.1
Applications
- Main and sub-circuit protection in electrical distribution boards
- Residential buildings with medium to high current requirements
- Commercial facilities with equipment prone to moderate inrush currents
- Light industrial setups requiring reliable circuit protection
Summary:
The 5SL6225-7 is a Siemens 2-pole, 25 A miniature circuit breaker with 400 V AC rating and 6 kA breaking capacity. Its Type C trip curve ensures dependable performance in circuits with moderate inrush currents, offering safe and efficient protection across various installation environments.
Frequently Asked Questions
What is the rule for installing an SPD?
✅ SPD (Surge Protection Device) connections should be as short as possible to minimize the voltage protection level (Up). The total length of connections to the network and earth should not exceed 50 cm to ensure effective surge protection.
How to Set Up a Surge Protector?
1.Turn off power at the circuit breaker.
2. Remove the old outlet.
3. Connect wires to the new surge-protected outlet per the manufacturer’s instructions.
4. Secure the outlet in the box and replace the cover plate.
5. Restore power and test the outlet.
What is the use of RCCB in Siemens?
✅ Siemens Residual Current Circuit Breakers (RCCBs) protect against electric shock by detecting leakage currents. If the leakage exceeds a set limit, the RCCB immediately disconnects the circuit, ensuring safety from direct or indirect contact with live components.
Where to Install RCCB?
✅ RCCBs should be installed in the distribution board (DB box) or circuit breaker panel to protect against current leakages caused by faulty wiring, ageing insulation, or defective appliances.
